background image

NX200S.xls Parts List 10/7/2002

YS #

Description

Qty. YS #

Description

Qty.

6410 GRN 3MM LED 1V7 5MA CLEAR BRT

1

8581 CUSTOM PBL TRANSISTOR SPACER

2

6425 BAV21 200V 0A25 DIODE T&R

2

4745 5.0W 0R1 5% BLK RES

2

6825 1N4148 75V 0A45 DIODE T&R

18

4729 5.0W 0R27 5% BLK RES

4

6438 1N4004 400V 1A0 DIODE T&R

4

4703 2.0W 2R 5% T&R RES

2

6827 1N5402 200V 3A0 DIODE

2

4905 1/4W 2R7 5% T&R RES

2

6434 6A2 200V 6A0 DIODE

4

2011 1/4W 11R3 1%FLAME PROOF T&R RES

2

6439 1N5225B 3V0 0W5 ZENER 5% T&R

1

2015 1/4W 33R2 1%FLAME PROOF T&R RES

4

6822 1N4745A 16V0 1W0 ZENER 5% T&R

2

6134 1/4W 47R 5%MINI T&R RES

2

6824 1N5246B 16V0 0W5 ZENER 5% T&R

2

4852 1/4W 100R 5% T&R RES

5

6463 1N5251BRL 22V0 0W5 ZENER 5% T&R

1

4987 1/4W 120R 5%MINI T&R RES

1

5101 BC550C TO92 NPN TRAN T&R TB

1

4909 1/4W 200R 5% T&R RES

1

5102 BC560C TO92 PNP TRAN T&R TB

2

4857 1/4W 220R 5% T&R RES

4

5103 MPSA06 TO92 NPN TRAN T&R TA

1

4986 1/4W 270R 5%MINI T&R RES

1

5104 MPSA56 TO92 PNP TRAN T&R TA

6

2028 1/8W 475R 1%FLAME PROOF T&R RES

4

5109 MPSA43 TO92 NPN TRAN TA

3

4743 1/4W 681R0 0.1% *** T&R RES

1

5106 MPSA63 TO92 PNP DARL T&R TA

2

4823 1/4W 1K 5% T&R RES

5

5122 J109 TO92 NCH JFET T&R TC

1

4889 1/4W 1K3 5% T&R RES

1

6814 MJF6668 T221D PNP TRAN DARL TJ

1

4769 1/4W 1K4 1% T&R RES

2

6815 MJF6388 T221D NPN TRAN DARL TJ

1

4824 1/4W 1K5 5% T&R RES

1

6902 TIP142 TO218 NPN TRAN DARL TE

2

4791 1/4W 1K54 1% T&T RES

1

6903 TIP147 TO218 PNP TRAN DARL TE

2

4705 2.0W 2K2 5% BLK RES

2

6840 MC33078P IC DUAL OP AMP

1

4847 1/4W 2K2 5% T&R RES

1

6882 TL072CP IC FET DUAL OP AMP

3

4883 1/4W 2K49 1% T&R RES

1

6889 TL074CN IC QUAD O/A T.I ONLY

1

4864 1/4W 2K7 5% T&R RES

1

6745 LM13600N IC XCONDUCTANCE AMP

1

4764 1/4W 2K740 0.1% *** T&R RES

1

6880 4N35 OPTO-COUPLER

1

4756 1/4W 4K120 0.1% *** T&R RES

1

6482 115R 20% 0W0 PTC THERMISTOR

1

4774 1/4W 4K12 1% T&R RES

3

5400 _10P 100V 10%CAP T&R BEAD NPO

1

4910 1/4W 4K3 5% T&R RES

1

5410 100P 100V 10%CAP T&R BEAD NPO

2

4627 1/2W 4K7 5% T&R RES

2

5197 220P 100V 2%CAP T&R RAD CER.2"NPO

2

4827 1/4W 4K7 5% T&R RES

5

5412 220P 100V 10%CAP T&R BEAD NPO

3

4762 1/4W 9K760 0.1% *** T&R RES

2

5416 470P 50V 10%CAP T&R BEAD NPO

2

4800 1/4W 10K0 1% T&R RES

1

6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC

1

4829 1/4W 10K 5% T&R RES

17

5300 _10N 50V 10%CAP T&R BEAD X7R

2

4775 1/4W 14K0 1% T&R RES

1

5210 _22N 100V 10%CAP T&R RAD .2"FLM

1

4771 1/4W 17K8 1% T&R RES

1

6435 _22N 275V 20%CAP BLK 'X2' 15MM AC

1

4832 1/4W 22K 5% T&R RES

2

5224 _47N 100V 10%CAP T&R RAD .2"FLM

2

4840 1/4W 33K 5% T&R RES

5

5228 100N 100V 5%CAP T&R RAD .2"FLM

4

4908 1/4W 45K3 1% T&R RES

3

5314 100N 50V 10%CAP T&R BEAD X7R

11

6119 1/4W 47K 5%MINI T&R RES

1

5229 150N 63V 10%CAP T&R RAD .2"FLM

3

4763 1/4W 82K50 0.1% *** T&R RES

4

5240 680N 63V 10%CAP T&R RAD .2"FLM

2

6120 1/4W 100K 5%MINI T&R RES

6

5255 __1U 63V 20%CAP T&R RAD .2"EL

2

4879 1/4W 270K 5% T&R RES

1

5256 __1U 63V 5%CAP T&R RAD .2"FLM

1

6127 1/4W 470K 5%MINI T&R RES

2

5945 _10U 63V 20%CAP T&R RAD .2"EL

1

4844 1/4W 1M 5% T&R RES

2

5260 _22U 50V 20%CAP T&R RAD .2"EL

1

3608 10" 9C-24AWG RIBBON HITMP 0.1"

1

5961 _33U 16V 20%CAP T&R RAD .2"NP

2

8742 4-40 X 3/8 PAN PH TAPTITE JS500

2

5267 100U 25V 20%CAP T&R RAD .2"EL

6

8823 6-32 X 1 PAN PH TAPTITE JS500

6

5630 330U 25V 20%CAP BLK 10X13MM EL

2

8998 6-32 X 1 FLAT PH MS ZINC CLEAR

3

5859 4700U 50V 20%CAP BLK 25X36MM ELS

2

8811 #6 X 1 1/4 FLAT RBTSN WOOD CLEAR ZN

8

4403 _10K 5B LIN 16MM P14

1

8803 8-32 X 3/8 PAN QUAD TAPTITE JS500

6

4520 _10K TRIM POT

1

8815 8-32 X 3/4 PAN PH TAPTITE JS500

10

713 25 X 20 X 50 2 MIL PLASTIC BAG

1

8624 10-32 X 1/2 HEX HD MS JS500 BLK

4

8483 ADAPTOR,SPEAKER STAND,METAL,BLACK

1

8781 #10 X 7/8 FLAT PHIL TYPE A JS500BLK

13

8547 PLASTIC FOOT BLACK

4

8727 #10 X 1" PAN PH TYPE A JS500 BLACK

16

3478 CLIP 205/187X032 18-22AWG DISCO/INS

2

8821 10-16 X 1 3/32 TYPE B HEX W/SLOT BL

2

3489 CLIP 250X032 18-22AWG DISCO/INSL

4

8862 #10 X 1 1/2 PAN PH TYPE A JS500

4

3491 CLIP 205/187X020 18-22AWG DISCO/INS

2

8751 10-32 X 2 PAN PH MS JS500

4

3682 250 MALE PCB TAB REEL

11

8777 #14 X 1FLAT PH TYPE A JS500 M6 HEAD

4

3498 1/4" JCK PCB MT HORZ

2

8906 #14X2 ALLEN FLAT HD WOOD SCRW JS500

4

3451 EYELET SMALL 0.089 OD PLATED

6

8607 3/16 NYLON SPACER OD 1/8 X ID .063

8

3414 INTERNATIONAL PC MOUNT FUSEHOLDER

2

3749 .375 SPACER ID.170 OD.31 NYLON

9

2407 2.5 AMP SLO-BLO .25X1.25 FUSE

1

7266 10" 2R 150WPGM SPEAKER

1

8537 TEARDROP HANDLE "YORKVILLE" BLUE

1

8485 #6 SPLIT WASHER ZINC

1

8604 10-32 T NUT

4

8473 #10 BLACK CUPWASHER SWF-10BK

1

3719 DUAL XSISTOR TO218 SPRING YEL PLTD

2

3421 DPDT PUSH SW PCMT MAKE B4 BREAK

2

3795 #8 GROUND LUG ZIERICK 505-169

1

3698 SPST ROKR SW QUIK 180" AC PWR BL/BL

1

3803 NYLON SECUR-A-TACH MINI PLASTIC TIE

1

8468 VELCRO STRAP 3/4"X22CM (VELSTRAP)

1

3810 4" NYLON CABLE TIE

6

1298 200B-K/MM-4/BETA-150 >1994"NEW"XFMR

1

8661 BUTTON KNOB FLAT GREY

2

8693 S ROTARY KNOB GREY

1

3481 8' 3/18 SJT AC LINE CORD 250 CLIPS

1

3834 HEYCO #1214 STRAIN RELIEF

1

"Y" LOGO SML. DOMED YORKVILLE BLUE

1

3676 8 CIR CABLE HOLDER .098

2

8701 4-40 KEPS NUT ZINC

2

8800 6-32 KEPS NUT ZINC

18

8854 6-32 X 1/4" 0.D. HEX NUT ZINC CLEAR

1

8787 8-32 KEPS NUT ZINC

2

8841 10-32 KEPS NUT ZINC

4

3866 ELASTOMER PAD TSIL 3 1.2X6.0

1
