Yorkville NX300-2 - Manual (Page 3)

nx300
YS No. Description Qty. YS No. Description Qty.
5949 _3U3 140AC 10%CAP BLK RAD POLYP FLM 1
5867 _15U 160AC 10%CAP BLK RAD POLYP FLM 1
3780 _220UH COIL 22AWG R000 BOBBIN 1
3878 1000UH COIL 18AWG R000 IRNLCORE 1
8483 ADAPTOR,SPEAKER STAND,METAL,BLACK 1
8538 RUBBER BUMPER W/ WASHER 1.375X1.375 3
3478 CLIP 205/187X032 18-22AWG DISCO/INS 2
3489 CLIP 250X032 18-22AWG DISCO/INSL 2
3924 1/4" JCK PCB MT VERT 2XTIP HICURNT 2
3628 SPKON 4C PCB MT VERT 250TAB GRY #4 2
8509 BLACK BLANK XOVERDISH PLASTIC CNFG1 1
3451 EYELET SMALL 0.089 OD PLATED 2
8933 1/4-20 INSIDE 7/16-20 UNF FLATALLEN 5
8508T LARGE DISH ALUMINIZED DECAL 1
8239D "Y" LOGO SML. DOMED YORKVILLE WHT. 1
3641 S.C BAYONET WIRE SOCKET TINNED 2
3644 12V 24W SC BAYONET #1156 BULB 2
3538 24 PIN BREAKAWAY LOCK .156 0.167
3549 TRIFURCON TERM .156 4
3558 TERM HOUSING 4 CIR .156/RAMP 1
3668 4 CIR CHASSIS MOUNT HDR .156 1
3903 PCB CONN 4 CIR BOTTOM .156 2
8701 4-40 KEPS NUT ZINC 2
8934 7/16-20 UNF HEX NUT GRD 5 CLEAR ZNC 5
4599 22AWG SOLID SC WIR T&R JMP 2
4700 10.W 8R2 5% BLK RES 4
5013 15.W 22R 5% BLK RES 1
9041 .093" HOLE .156" STAG 16GA 36"X120" 4
8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK 4
8798 4-40 X 1.00 PAN PH MS ZINC 2
8874 8-32 X 1" PAN PHIL TAPTITE JS500 4
8843 10-32 X 1 1/8 FLAT PH MS JS500 16
8786 10-32 X 1 1/4 PAN QD MS JS500 BLACK 20
8751 10-32 X 2 PAN PH MS JS500 3
8935  1/4-20 X 23MM JOINT CON. BOLT B/O 4
8903  M5 X 16 DIN 7985 HH ZINC SCREW 2
8995 3/8" STEEL FLAT WASHER,ZINC CLEAR 5
3744 SNAP IN .375 SPACER RICHCO 4
SPK7457 15" 8R 300WPGM SPEAKER 1
8908 #10 SAE FLAT WASHER .25"ID .565" OD 14
8489 1/4-20 SPLIT WASHER ZINC 14
8492 7/16" SPLIT LOCK WASHER CLEAR ZINC 5
8996 3/8" SPLIT WASHER 5
