Day Bed Conversion

A. Remove the 6 bolts attaching the guard rail to the crib, and remove the guard
rail. Save all hardware for future reassembly of your crib.
B. Insert the allen bolt (P) through the hole in the corner post, and thread it into
the cap nut as shown. Tighten securely using the allen wrench.
C. Repeat with the other 5 holes.

Required Hardware

6 x Allen Bolt, 1-1/8” Long (P)

Allen Wrench (R)

6 x Cap Nut (Q)

Allen Bolt (P)

Cap Nut (Q)
