Hardware setup – Asus INTEL 850 ATX User Manual
Page 10
10
HP WMT-LX User’s Manual
2. HARDWARE SETUP
Step 3: Install the Heatsink Support Base
Place the two heatsink support base as shown and screw in the four pan head screws.
Step 4: Install the Heatsink
C arefully place the fan heatsink on top of the heatsink support base and connect the
fan power cable to the C PU fan connector.
C onnect to the
C PU fan connector.
