Audiovox Prestige P153B - Manual (Page 3)

OPERATING INSTRUCTIONS
-3-
1
POWER ON-OFF BUTTON ( PWR )
Press this button to turn the unit on or off. If the ignition switch is
“on”, the unit will turn on automatically when a compact disc or
audio cassette is inserted.
2
AUDIO (LEVEL) CONTROL (VOLUME +/-)
To increase the volume level, turn the VOLUME +/- knob clock-
wise (+ direction). VOL will appear and the volume level will be
shown on the display panel from a minimum of V -- 0 to a
maximum of V -- 46. To decrease the volume level, turn the
knob counter-clockwise (- direction). The display will automati-
cally return to the normal indication 5 seconds after the last vol-
ume adjustment or when another function is activated. This con-
trol is also used in conjunction with the Select (SEL) control button
!
to adjust the bass, treble, balance and fader levels as described
in
"
,
#
,
$
and
%
.
3
SELECT (SEL) CONTROL BUTTON
This button is used to select the audio function (volume, bass,
treble, balance, or fade) whose setting is adjusted using the
VOLUME +/- control
. Pressing the SEL button once will set
the unit for volume (VOL) adjustment as described previously.
1
2
3, 4, 5, 6, 7
8
10
25
26
9
11,13 12 32 30 31 29 28
14
20,21 22,32
17
35
36,37
16 18 27
38
15
P-153B
DIS P
33
34
19
23
24
