Other PS225 Manuals and Related Component Manuals
Description Part Number
PS225 Operators Manual …………………………………………………. 33755
PS225 Installation Manual ………………………………………………… 34453
AWI (Advanced Wash Insert) Owner’s Manual Supplement ………….. 33754
Wall Chart AWI Installation Instructions …………………………………. 34293
PS225 UPM Programming Manual ………………………………………. 35519
Soap Dispenser Installation Manual ……………………………………… 27173
Wiring Diagrams
The following wiring diagrams are the two most common wiring methods for the PS225.
The wiring diagram for a machine that is constructed with a wiring configuration other
that those shown can be obtained by contacting the Power Soak service department at
800-444-9624.
