Power Soak 33754 AWI Owner's Manual User Manual
Page 5
3
2. Rib Sets
Next identify the end of the wash tank you would prefer to use as the utensil
washing region. In Power Soak Generation 4 units, this will be the end closest to
the pump. You will find a large space between the first and second jets on these
units. The pump is at the left end of the wash tank on some models and at the right
end on others. On Generation 3 Power Soaks, either end is acceptable as a utensil
washing region.
Place a narrow rear rib section (two ribs wide) in the rear corner of the wash tank.
Now place a narrow front rib section (two ribs wide) in the front corner of the wash
tank adjacent to the narrow rear rib section just installed.
Large space between Jet
1 and Jet 2 in Generation
4 Power Soaks
Narrow
rear rib
section
Narrow front
rib section
