Abocom FSW410 User Manual
Features

802.11g 2.4GHz Wireless Router
with 4-Port Fast Ethernet Switch
+ USB1.1 Host
The FSW410 is an 802.11g Wireless Broadband Router with 4-port Fast Ethernet
Switch and an USB 1.1 host. The FSW410 offers complementary extensions to
existing wired LAN, the wireless users can painlessly have access to the Internet as
LAN users. With the built-in NAT capability, the FSW410 allows SOHOs to
share a broadband Modem with single IP account simultaneously from different
rooms without the hassle of cabling.
The integrated USB 1.1 port allows this router to accommodate an USB storage
device.
Features
Internet Access Features
•
Shared Internet Access.
All users on the LAN or WLAN can access the Internet through the Wireless Router,
using only a single external IP Address. The local (private) IP Addresses are hidden from external sources. This
process is called NAT (Network Address Translation).
•
DSL & Cable Modem Support.
The Wireless Router has a 10/100BaseT Ethernet port for connecting a DSL or
Cable Modem. All popular DSL and Cable Modems are supported.
•
PPPoE Support. The Internet (WAN port) connection supports PPPoE (PPP over Ethernet),
Unnumbered IP with PPPoE is also supported.
•
Dynamic IP Address.
On the Internet (WAN port) connection, the Wireless Router support Dynamic IP Address
(IP Address is allocated on connection) .
Advanced Internet Functions
•
Special Internet Applications.
Applications, which use non-standard connections or port numbers, are normally
blocked by the Firewall. The ability to define and allow such applications is provided to enable such applications to
be used normally.
•
Server Port.
The Server Port function enables users to set a local server with specific port number that stands for
the service (e.g. web(80), FTP(21), Telnet(23)). When this device receives an incoming access request for this
specific port, it will be forwarded the request to the corresponding internal server.
•
ALG.
Network traffic that matches the service definition
•
DDNS Support.
DDNS (Dynamic DNS) allows Internet users to connect to Virtual Servers on your LAN using a
domain name, even if your IP address is not fixed.
•
DMZ.
One (1) PC on your local LAN can be configured to allow unrestricted 2-way communication with Servers
or individual users on the Internet.
•
URL Filter.
Use the URL Filter to block access to undesirable Web sites by LAN users.
Wireless Features
•
Support IEEE 802.11g Wireless Stations.
The IEEE 802.11g standard provides for backward compatibility
with the standard 802.11g Wireless stations.
•
WEP support.
Support for WEP (Wired Equivalent Privacy) is included. Key sizes of 64 Bit and 128 Bit are
supported.
•
Wireless MAC Access Control.
The Wireless Access Control feature can check the the MAC address (hardware
address) of Wireless stations to ensure that only trusted Wireless Stations can access your LAN.
•
Simple Configuration.
If the default settings are unsuitable, they can be changed quickly and easily.
LAN Features
•
4-Port Switching Hub.
The Wireless Router incorporates a 4-port 10/100BaseT switching hub, making it easy
to create or extend your LAN.
