Napoleon Fireplaces GVFS60 - Manual (Page 2)

NOTE: Changes, other than editorial, are denoted by a vertical line in the margin
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.2 GENERAL INSTRUCTIONS 5
2.3 GENERAL INFORMATION 6
2.4 RATING PLATE INFORMATION 7
2.5 SHIPPING BRACKET 7
3.0 INSTALLATION 8
3.1 COMBUSTION AND VENTILATION AIR PROVISIONS 8
3.2 DETERMINING CONFINED OR UNCONFINED SPACE 9
3.3 GAS INSTALLATION 10
3.4 OPTIONAL WALL SWITCH 11
3.5 MOBILE HOME 11
4.0 FINISHING 11
4.1 CAST FRONT REMOVAL 11
4.2 LOG PLACEMENT 12
4.3 LOGO PLACEMENT 13
5.0 BLOWER INSTALLATION 13
5.1 SWITCH AND BRACKET INSTALLATION 14
6.0 OPERATION 15
7.0 ADJUSTMENT 16
7.1 VENTURI ADJUSTMENT 16
7.2 FLAME CHARACTERISTICS 16
8.0 MAINTENANCE 17
8.1 OXYGEN DEPLETION SENSOR PILOT CLEANING 17
9.0 REPLACEMENTS 18
10.0 TROUBLESHOOTING 20
11.0 WARRANTY 23
12.0 SERVICE HISTORY 24
2
W415-0796 / C / 03.19.12
