23
W415-1016 / B / 03.13.12
10.0 REPLACEMENTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE
REQUIRED TO HONOUR THE CLAIM.
When ordering replacement parts always give the following information:
•
Model & Serial Number of appliance
• Installation date of appliance
• Part number
• Description of part
• Finish
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR
FURTHER INFORMATION, CONTACT YOUR AUTHORIZED DEALER.
41.1
FAILURE TO POSITION THE PARTS
IN ACCORDANCE WITH THIS
MANUAL OR FAILURE TO USE ONLY
PARTS SPECIFICALLY APPROVED
WITH THIS APPLIANCE MAY
RESULT IN PROPERTY DAMAGE OR
PERSONAL INJURY.
!
WARNING
COMPONENTS
REF NO. PART NO. DESCRIPTION
1 W010-2334 BLACK DOOR FRAME
2 W725-0065 NATURAL GAS VALVE
2 W725-0066 PROPANE GAS VALVE
3* W385-0334 NAPOLEON® LOGO
4 W662-0008 NATURAL GAS PILOT
4 W662-0009 PROPANE PILOT
5 W456-0045 #45 NATURAL GAS ORIFICE
5 W456-0056 #56 PROPANE ORIFICE
6* W300-0142 CRUSHED GLASS
7 W010-2440 REPLACEMENT GLASS C/W GASKET
8 W190-0029 CONTROL, IPI IGNITION BOARD
9 W710-0035 TRAY, MEDIA
10 W660-0009 ON/OFF SWITCH
11 W137-0001 CATALYST
12 W750-0252 WIRE, SENSOR
13 W750-0251 WIRE, IGNITOR
14 W475-0727 TOP FIBER PANEL
15 W475-0726 REAR FIBER PANEL
16* W350-0517 BATTERY HOUSING
