ARRIFLEX 416 Quick Guide 04/2007, Page 4
Camera Left & Front
RUN
PHASE
NORM PS/CCU LOCK
MODE SEL/∆ SET/ V
DIMMER
— +
Image rotation knob
Tape hook
PL lens port
(Super 16 only)
Front 3/8 – 16
mounting point
Heated Eyepiece
outlet
RGB ARRIGLOW
brightness buttons
PHASE button
RUN button
Image rotation
knob
Eyepiece focus ring
416 Standard
Camera Handle
Timecode sensitivity
switch
Magazine feed
side door lock
416 Shoulder
Magazine 120/400
Display
Tape hook
RUN Indicator
Flip-out tape hook
Optional centre leg
Image rotation unlock
button
Image rotation
unlock button
