Ersa VERSAPRINT
Technical data & machine options
Machine options matrix: VERSAPRINT P1 VERSAPRINT S1
LIST camera x x
Standard camera option option
Triple rail 310 mm - parallel processing x –
Triple rail 420 mm - parallel processing option –
Single rail - serial processing – x
Stencil cleaner - with vacuum x x
Dispenser (stencil) option option
Dispenser (PCB) option option
Data matrix / bar code option option
Set-up control option option
SPC option option
Temperature control option option
219351 - 092013 | Subject to changes | © 2013 by Ersa GmbH
Ersa GmbH
Leonhard-Karl-Str. 24
97877 Wertheim
Germany Tel. +49 9342 800-0
Fax +49 9342 800-100
[email protected]
www.kurtzersa.de
Technical data: VERSAPRINT P1 VERSAPRINT S1
Substrate handling
Substrate size (X x Y) [mm] min. 80 x 50; max. 460 x 460 min. 80 x 50; max. 550 x 500
Triple Rail Transport mode [mm]
min. 80 x 50; max. 310 x 460
optional: max. 420 x 460
Substrate thickness [mm] 0.5 - 6 0.5 - 6
Stencil mount
Stencil size [mm]
min. 450 x 450; max. 737 x 737
Adjustable without adapter min. 450 x 450; max. 737 x 737
Adjustable without adapter
Print head
2 independent print heads; continuous pres-
sure control in a closed-loop system; adjust-
able squeegee down stop weight compensa-
tion for different squeegee length 2 independent print heads; continuous pres-
sure control in a closed loop-system; adjust-
able squeegee down stop weight compensa-
tion for different squeegee length
Print force [N] 0 - 260 0 - 260
Vision
Camera
2 line scan cameras, one for each direction
(stencil/PCB) 2 line scan cameras, one for each direction
(stencil/PCB)
Programming Proprietary “Teach In” method Proprietary “Teach In” method
Performance
Repeatability ± 12.5 µm @ 6 Sigma ± 12.5 µm @ 6 Sigma
Print accuracy ± 25 µm @ 6 Sigma ± 25 µm @ 6 Sigma
Cycle time [s] < 12 + print < 14 + print
Inspection speed 9,100 mm²/s (L: 260 mm x 35 mm/s) 9,100 mm²/s (L: 260 mm x 35 mm/s)
Setup time [min] < 10 < 10
Product change [min] < 2 < 2
Machine operation
Graphic user interface
SEMI Standard E95-1101 SEMI Standard E95-1101
Machine dimensions
Width x depth x height [mm]
approx. 1490 x 1850 x 1607 approx. 1190 x 1850 x 1607
