Subwoofer Subwoofer
2
Subwoofer Specifications
ACWD “Performance” Series DVC Subwoofers
1000 1200 1500
Diameter (in.) 10” 12” 15”
Cone Material Non-Pressed Paper Non-Pressed Paper Non-Pressed Paper
Basket Stamped Steel Stamped Steel Stamped Steel
Surround NBR NBR NBR
Voice Coil Dia. & Type 2” #P600 2” #P600 2” #P600
Magnet Weight (oz.) 35 45 60
Mounting Diameter (in.) 9.17 10.95 13.77
Mounting Depth (in.) 5.11 5.57 6.50
EXONIC “Competition” Series DVC Subwoofers
1000 1200 1500
Diameter (in.) 10” 12” 15”
Cone Material Non-Pressed Paper Non-Pressed Paper Non-Pressed Paper
Basket Die-Cast Alloy Die-Cast Alloy Die-Cast Alloy
Surround NBR NBR NBR
Voice Coil Dia. & Type 2” #P600 2” #P600 2” #P600
Magnet Weight (oz.) 45 50 65
Mounting Diameter (in.) 9.25 10.98 13.93
Mounting Depth (in.) 4.94 5.47 6.81
EXONIC “Extreme” Series DVC Subwoofers
10X 12X
Diameter (in.) 10” 12
Cone Material Honeycomb Honeycomb
Basket Die-Cast Alloy Die-Cast Alloy
Surround NBR NBR
Voice Coil Dia. & Type 3” #P600 3” #P600
Magnet Weight (oz.) 160 200
Mounting Diameter (in.) 9.25 10.98
Mounting Depth (in.) 6.43 6.96
7
Exonic “Extreme” Series DVC Subwoofers
SEALED VENTED BANDPASS
10X cu. ft Vb1 .60 1.46 Sealed .71
cu. ft Vb2 Ported .58
Port (qty.) DxL (1) 4”x13” (1) 4”x12.7”
Fb Tunning Freq. 40Hz 65Hz
12X cu. ft Vb1 .75 2.5 Sealed 1.3
cu. ft Vb2 Ported 1.37
Port (qty.) DxL (2) 4”x12.86” (1) 6”x12.4”
Fb Tunning Freq. 38Hz 60Hz
* The Exonic “Extreme” 10X and 12X subwoofers can be used in a wide
range of enclosure sizes. The specified sizes reflect both sound quality
and high output usage. For those in need of extreme SPL designs,
requiring higher tuned enclosures, please contact your local Authorized
Dealer or call Ample Audio direct.
** All of the specified enclosures can be categorized as Optimum or
Recommended sizes. However, the performance of these enclosures
may vary due to vehicle type and amplifier power. In addition, properly
designed and built enclosures are necessary for exceptional speaker per-
formance. Your local Authorized dealer or an Ample Audio technical
support person can assist with any questions you may have.
