Fixture and accessories, Dimension – Agilent Technologies FIXTURE U7242A User Manual
Page 6
6
Fixture and Accessories
The complete set of USB3.0 test fixture contains the following items:
Dimension
The dimension of the U7242A test fixture board is as follows:
PCB board height = 2.00 inches
PCB board width = 7.75 inches
PCB board thickness = 0.063 inches
Part Number
Description
Quantity
U7242-66501
USB 3.0 test fixture
1 unit
8121-1880
USB 3.0 Std-A to Std-B cable (4 inches)
1 unit
8121-1924
USB 3.0 Std-A to Std-B cable (3.1 inches)
1 unit
1253-8358
Double Banana Plug With Shorting Bar
1 unit
