www.avenview.com 7
1.9 General Troubleshooting
Problem Possible Solution
No Image 
Check if connection to the source and the display are correct.
Screen Defects Appear

Check the cable connections
Section 2: Specifications
Item Description
Video Bandwidth 270 Mbps, 1.485 / 1.001 Gbps
Input Signal HD/SD-SDI (SMPTE 259M, SMPTE 292M, SMPTE 296M)
Output Signal HDMI (video only) / DVI 1.1 / Component / RGBHV
Input Transmission
Range
150 meter (500 feet) at HD-SDI
Loop Output 2 equalized SDI
Power Supply 5V DC, 4Amp
Dimension (L x W x H) 4.7” x 4.3” x 1”
Weight 420g (15oz)
Environmental
Operation
0˚ to 50˚C Degree
2.1 Format Specifications
HD Input Component Out
525p @ 59.94Hz SMPTE 293M, ITU-BT.1358
625p @ 50Hz IT-BT.1358
720p @ 50Hz SMPTE 296M-3 √
720p @ 60 / 59.94 Hz SMPTE 296M-1,2 √
1080i @ 25Hz SMPTE 274M-6 √
1080i @ 30 / 29.97Hz SMPTE 274M-4,5 √
1080p @ 24 / 23.98Hz SMPTE 274M-10,11 √
1080p @ 25Hz SMPTE 274M-9 √
1080p @ 30 / 29.97Hz SMPTE 274M-7,8 √
SD Input
NTSC √
PAL B, D, G, H, I √
