Specifications
Function CS-1732 CS-1734
Computer Connections 2 4
CPU Port Selection Front Panel Switches; Hotkey
USB Port Selection Hotkey
LEDs On Line 2 (Orange) 4 (Orange)
USB Link 2 (Green) 4 (Green)
Console
Connectors Keyboard 1 x USB Type A
Mouse 1 x USB Type A
Video 1 x HDB -15 female
Audio 1 x Stereo port
1 x Microphone port
CPU
Connectors KVM data 2 x SPDB - 15 female 4 x SPDB - 15 female
Audio 2 x Stereo ports
2 x Microphone ports 4 x Stereo ports
4 x Microphone ports
USB Peripherals 2 x USB Type A
Firmware Upgrade 1 x RJ- 11socket
Power Adapter 1 x DC 5V jack
Scan Interval 5 secs.
Resolution Up to 2304 x 1440
Power Consumption Bus Powered
Operating Temperature 5 - 40
o
C
Storage Temperature -20 - 60
o
C
Humidity 0 - 80% RH
Housing Metal
Weight .49 kg .70 kg
Dimensions (L x W x H) 13.0 x 7.45 x 4.2cm 20 x 7.45 x 4.2cm
2003-07-17
CS-1732 / CS-1734 User Manual 27
