Apple TV User Manual
Page 15
Chapter 2
Getting Started
15
To connect a widescreen TV and a receiver:
1
Connect an HDMI or component video cable between your TV and Apple TV.
2
Connect an optical digital or analog audio cable to your receiver and Apple TV.
Note:
Alternatively, you can connect a video cable between Apple TV and your receiver
and then connect a video cable between your receiver and TV.
optical
audio
£
G
d
audio
video
R
L
HDMI cable
HDMI port
Apple TV
Home
theater
receiver
Speakers
TV
HDMI port
Optical digital audio port
