3
M
ODELS
Domestic
Model 932045 (8524E)
8.5H.P. 24” Sno-Thro
Serial No. 000101 and up
Model 932046 (724E)
7H.P. 24” Sno-Thro
Serial No. 000101 and up
Model 932047 (5524E)
5.5H.P. 24” Sno-Thro
Serial No. 000101 and up
Model 932048 (5520)
5.5H.P. 20” Sno-Thro
Serial No. 000101 and up
International
Model 932311 (5520)
5.5H.P. 20” Sno-Thro
Serial No.00101 and up
Model 932312 (7524)
7.5H.P. 24” Sno-Thro
Serial No.00101 and up
T
ABLE
O
F
C
ONTENTS
D
ECALS
Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
E
NGINE AND
D
RIVE
Engine and Belt Drive . . . . . . . . . . . . . . . . . . . . . . . . 6
Friction Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
F
RAME AND
H
OUSING
Handlebars and Controls . . . . . . . . . . . . . . . . . . . . . 12
Auger and Chute . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Discharge Chute Crank . . . . . . . . . . . . . . . . . . . . . . 16
Gearcase and Impeller. . . . . . . . . . . . . . . . . . . . . . . 18
