Asus WL-520G - Manual (Page 19)

WL-520g Wireless Router User Manual
18
6
4
5
3
1
2
First, we are to set up AP1. Choose Bridge in the
Wireless folder.
Set the SSID as WL520g and
WEP Encryption as None.
We suggest AP1 and AP2
using the same SSID.
Select WAN & LAN in the IP Config folder.
Confirm that the IP address
of AP1 is 192.168.1.1.
Enter the Bridge page again.
Select Hybrid as AP mode.
Thus, AP1 will be both AP
and WDS. If you want to use
wireless function only, please
choose WDS Only.
7
Select a fixed channel for
WDS. In this example, we set
it as Channel 3.
When you choose WDS or Hybrid mode, you will see
a message demanding a fixed channel for WDS.
8
