American Megatrends III User Manual
Page 17
Chapter 1 Hardware Installation
13
Step
Action
2
Check for bent pins on the CPU. Gently straighten any bent
pins with pliers. Place the CPU in the middle of the socket,
as shown below. Make sure that pin 1 of the CPU is aligned
with pin 1 of the socket. Make sure you are properly
grounded while handling the CPU.
3
Complete installation by lifting the ZIF lever to the other
side of the socket, as shown below.
