Alto-Shaam SC-24/2S User Manual
Page 2
D I M E N S I O N S :
H x W x D
SC-24/2S
EXTERIOR
:
29-3/8" x 29" x 23" (747mm x 739mm x 589mm)
SHELF DIMENSION
:
24"W x 23"D (610mm x 589mm)
SC-36/2S
EXTERIOR
:
29-3/8" x 41" x 23" (747mm x 1044mm x 589mm)
SHELF DIMENSION
:
36"W x 23"D (915mm x 589mm)
C L E A R A N C E R E Q U I R E M E N T S
3" (76mm) at top for ventilation.
INSTALLATION REQUIREMENTS
Unit must be installed level. It must not be kept
in any area where it may be affected by steam,
grease, dripping water, high temperatures, or any
other severely adverse conditions.
WEIGHT
SC-24/2S
SC-36/2S
NET
85 lb est. (39 kg)
105 lb (48 kg)
SHIP
215 lb est. (98 kg)
230 lb (104 kg)
CARTON DIMENSIONS
:
H X W X D
45"
X
45"
X
45"
45"
X
53"
X
45"
(1143 x 1143 x 1143mm)
(1143 x 1346 x 1143mm)
ELECTRICAL
CORD
&
PLUG
VOLTAGE PHASE CYCLE
/
HZ AMPS
kW
INCLUDED
120
1 50/60
12.0
1.4
230
1 50/60
CONTACT FACTORY
120
1 50/60
16.0
1.9
230
1 50/60
CONTACT FACTORY
SC-36/2S
SC-24/2S
SC-36/2S
HOT FOOD COUNTERTOP MERCHANDISER
P R O D U C T C A PA C I T Y
FOR USE WITH PRE
-
PACKAGED FOODS ONLY
SC-24/2S: 12 wrapped sandwiches per shelf
SC-36/2S: 24 wrapped sandwiches per shelf
4
3
2
1
24" (610mm)
2-1/2" (65mm)
23-7/16" (595mm)
29" (739mm)
29" (738mm)
3/8" (10mm)
23-7/16" (595mm)
11" (282mm)
9" (233mm)
4
3
2
1
3
2
1
I:\Eng\Projects\730831 SC Series\Assemblies\
5002816 .SLDDR
36" (915mm)
2-1/2" (65mm)
11" (282mm)
23-7/16" (595mm)
41" (1044mm)
29" (737mm)
3/8" (10mm)
23" (589mm)
10-1/2"
(265mm)
SC-24/2S
SC-36/2S
SC-24/2S
NEMA
5-20
P
20A-125
V PLUG
NEMA
5-20
P
20A-125
V PLUG
O P T I O N S & A C C E S S O R I E S
■
■
SC-24 Divider Bar Kit
5004543
■
■
SC-36 Divider Bar Kit
5004544
#75 - 11/08
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE
: 262.251.3800 800.558.8744
U
.
S
.
A
./
CANADA
FAX
: 262.251.7067 800.329.8744
U
.
S
.
A
.
ONLY
www.alto-shaam.com
D U E TO O N G O I N G P R O D U C T I M P R O V E M E N T
,
S P E C I F I C AT I O N S A R E S U B J E C T TO C H A N G E W I T H O U T N O T I C E
.
