6
NOTE: ADC reserves the right to make changes in specifications at any time, without notice or
obligation.
SECTION II
SPECIFICATIONS/COMPONENT IDENTIFICATION
A. SPECIFICATIONS
Gas
BASKET (
TUMBLER
) DIAMETER 37" 94 cm
BASKET (
TUMBLER
) DEPTH 36" 91.5 cm
BASKET (
TUMBLER
) MOTOR 3/4 HP* .560 kw
DOOR OPENING (D
IAMETER
) 21-1/2" 54.61 cm
BASKET (
TUMBLER
) VOLUME 22.4 cu. ft. .634 cu.m.
DRYERS PER 20'/40' CONTAINER 10/20
DRYERS PER 6 m/12 m CONTAINER 10/20
DRYERS PER 45'/48' TRUCK 24/26
DRYERS PER 14 m/15 m TRUCK 24/24
VOLTAGE AVAILABLE 120-460v / 1ш-3ш / 3, 4w / 50/50 Hz
APPROX. WEIGHT (
UNCRATED
) 721 lbs. 327.1 kg
APPROX. WEIGHT (
CRATED
) 771 lbs. 349.7 kg
HEAT INPUT 175,000 btu/hr 44,100 kcal/hr
AIRFLOW 750 cfm 21.24 cm
INLET PIPE SIZE** 3/4" 1.91 cm
Shaded areas are stated in metric equivalents
* For Non-Reversing Models.
** A minimum of 3/4" (1.91 cm) must be supplied to the gas inlet for each dryer.
