ADSST-SALEM-3T
Rev. 0 | Page 8 of 24
ADSST-218X ELECTRICAL CHARACTERISTICS
Table 4.
Parameter Test
Conditions
Min
Typ
Max
Unit
V
IH
High Level Input Voltage
1, 2
@ V
DDINT
= Max
1.5
V
V
IH
High Level CLKIN Voltage
@ V
DDINT
= Max
2.0
V
V
IL
Low Level Input Voltage
1, 3
@ V
DDINT
= Min
0.7
V
V
OH
High Level Output Voltage
1, 4, 5
@ V
DDEXT
= Min, I
OH
= –0.5 mA
2.0
V
@
V
DDEXT
= 3.0 V, I
OH
= –0.5 mA
2.4
V
@
V
DDEXT
= Min, I
OH
= –100 µA
6
V
DDEXT
– 0.3
V
V
OL
Low Level Output Voltage
1, 4, 5
@ V
DDEXT
= Min, I
OL
= 2 mA
0.4
V
I
IH
High Level Input Current
3
@ V
DDINT
= Max, V
IN
= 3.6 V
10
µA
I
IL
Low Level Input Current
3
@ V
DDINT
= Max, V
IN
= 0 V
10
µA
I
OZH
Three-State Leakage Current
7
@ V
DDEXT
= Max, V
IN
= 3.6 V
8
10
µA
I
OZL
Three-State Leakage Current
7
@ V
DDEXT
= Max, V
IN
= 0 V
8
10
µA
I
DD
Supply Current (Idle)
9
@ V
DDINT
= 2.5 V, t
CK
= 15 ns
9
mA
@
V
DDINT
= 2.5 V, t
CK
= 13.3 ns
10
mA
I
DD
Supply Current (Dynamic)
10
@ V
DDINT
= 2.5 V, t
CK
= 13.3 ns
11
, T
AMB
= +25°C
35
mA
@
V
DDINT
= 2.5 V, t
CK
= 15 ns
11
, T
AMB
= +25°C
38
mA
I
DD
Supply Current (Power-Down)
12
@ V
DDINT
= 2.5 V, T
AMB
= +25°C in Lowest Power Mode
100
mA
C
I
Input Pin Capacitance
3, 6
@ V
IN
= 2.5 V, f
IN
= 1.0 MHz, T
AMB
= +25°C
8
pF
C
O
Output Pin Capacitance
6, 7, 12, 13
@ V
IN
= 2.5 V, f
IN
= 1.0 MHz, T
AMB
= +25°C
8
pF
1
Bidirectional pins: D0–D23, RFS0, RFS1, SCLK0, SCLK1, TFS0, TFS1, A1–A13, PF0–PF7.
2
Input only pins: RESET, BR, DR0, DR1, PWD.
3
Input only pins: CLKIN, RESET, BR, DR0, DR1, PWD.
4
Output pins: BG, PMS, DMS, BMS, IOMS, CMS, RD, WR, PWDACK, A0, DT0, DT1, CLKOUT, FL2–0, BGH.
5
Although specified for TTL outputs, all ADSP-2186 outputs are CMOS compatible and will drive to V
DDEXT
and GND, assuming no dc loads.
6
Guaranteed but not tested.
7
Three-statable pins: A0–A13, D0–D23, PMS, DMS, BMS, IOMS, CMS, RD, WR, DT0, DT1, SCLK0, SCLK1, TFS0, TFS1, RFS0, RFS1, PF0–PF7.
8
0 V on BR.
9
Idle refers to ADSST-218x state of operation during execution of IDLE instruction. Deasserted pins are driven to either V
DD
or GND.
10
I
DD
measurement taken with all instructions executing from internal memory. 50% of the instructions are multifunction (Types 1, 4, 5, 12, 13, 14), 30% are Type 2 and
Type 6, and 20% are idle instructions.
11
V
IN
= 0 V and 3 V. For typical figures for supply currents, refer to the Power Dissipation section.
12
Applies to LQFP package type.
13
Output pin capacitance is the capacitive load for any three-stated output pin.
