– 1 –
For assistance, please call: 1-800-ADT-ASAP
2.4 GHz Expandable Cordless Handset
Model No.
KX-TGA290
Installation Manual
PLEASE READ BEFORE USE AND SAVE.
This handset is an accessory cordless handset, for use with Panasonic base unit
KX-TG2970. This installation manual only describes the steps necessary to start up the
handset. Please read the base unit operating instructions for further details.
Installation
Connecting the Charger unit
• USE ONLY WITH Panasonic AC ADAPTOR KX-TCA1 (Order No. KX-TCA1-G).
• The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel
warm during use.)
• The AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet.
Do not connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the
adaptor may cause it to become disconnected.
Installing the battery
Insert the battery ( 1) , and press it down until it snaps into the compartment ( 2) .
Close the cover.
PQQX14266ZA S0804-1094
Accessories (included) For extra orders, call 1-800-332-5368.
A Charger Unit . . . . . . . . . . . . . . . . . . . . . . . . .1
Charger Order No. PQLV30028ZB
AC Adaptor Order No. KX-TCA1-G (KX-TCA1)
A Handset Cover. . . . . . . . . . . . . . . . . . . . . . . .1
Order No. PQYNTG2970BR
A Battery . . . . . . . . . . . . . . . . . . .1
Order No. HHR-P402
A Belt Clip . . . . . . . . . . . . . . . . . .1
Order No. PQKE10340Z2
CHARGE
Power Outlet
(AC 120 V, 60 Hz)
AC Adaptor
2
1
