2 Long screws (ST4.2X20)

2. Install header between joists by using nails or screws.

3. Install the fan body and secure it by using long

screws (ST4.2X20). (Fig.20, Fig.21)

1. Before installation, secure the

to

by

using thumb screw (Fig.13 of page 10) Secure the
lighting unit to fan body (refering to Fig.6 of page 8).

fan body

adaptor

.

11

3. Insert the fan body between joists.

Make sure the fan body is level and square
(perpendicular) with the joists. (Fig.17)

4. Secure the suspension bracket to joists by using long

screws (ST4.2X20). (Fig.18, Fig.19)

5. Secure the suspension bracket to fan body by using

screw

(ST4.2X12). (Fig.19)

II

6. Follow step 5 to 11 of installation (page 7~page 8)

to complete the installation work.

I

INSTALLATION

WOODEN HEADE

V (

R )

INSTALLATION

WOODEN HEADE

V (

R )

INSTALLATION

JOIST MOUNTING

IV ( BETWEEN

) CONTINUED

INSTALLATION

JOIST MOUNTING

IV ( BETWEEN

) CONTINUED

Fig.18

Fig.17

inches mm

(

)

Junction box

Fan body

Joists

Adaptor

inches (mm)

Fig.20

Adaptor

Joist

Header

Header

Joist

(275)

(375)

10

7/8

14 3/4

Fig.19

2 Screw
(ST4.2X12)

II

Joist

4 Long screws
(ST4.2X20)

13 1/4~15 1/2 ( 336~394 )
16 1/2~18 3/4 ( 419~480 )
21 1/4~23 1/2 ( 540~597 )

Suspension bracket

A

CAUTION:

Fan body

Joist

Backside of flange should mount directly to bottom of joist.
