6. APPENDIX
Name of Parts ■
Water drain
Ceiling panel
(optional)
Air outlet
(4 locations)
Air intake grille
(air intake)
4-Way Cassette type (U1 type)
Water drain
Flexible duct
(optional)
Canvas duct
(optional)
Air intake grille
(air intake)
(optional)
Air outlet grille
(optional)
Low Silhouette Ducted type (F1 type)
Water drain
Air intake
grille (air
intake)
Air outlet
(Drain pipe can be
connected to
either the left or
right side.)
Ceiling type (T1 type)
Air outlet
Air intake
Wall Mounted type (K1 type)
