PMC Pn4 User Interface Pin Assignment
The figure provides the pin assignments for the PMC-4U Module routed to
Pn4. Also, see the User Manual for your carrier board for more
information.
GND
IO_0+ (UART Rx A)
1
2
IO_1+
IO_2+ (UART Rx B)
3
4
IO_3+
IO_4+ (UART Rx C)
5
6
IO_5+
IO_6+ (UART Rx D)
8
9
IO_7+
GND
9
10
IO_8+ (UART Tx A)
IO_9+ (UART Tx B)
11
12
IO_10+ (UART Tx C)
IO_11+ (UART Tx D)
13
14
IO_12+
IO_13+ (SCC Rx B)
15
16
IO_14+
IO_15+ (SCC Tx B)
17
18
GND
IN_0
19
20
IN_1
IN_2
21
22
IN_3
IN_4
23
24
IN_5
IN_6
25
26
IN_7
GND
27
28
AUX_IN_0 (SCC Rx A) AUX_IN_1 (SCC Rx Clk)
29
30
GND
+3.3 V REF
31
32
+6.5 V REF
-6.5 V REF
33
34
GND
IO_0- (UART Rx A)
35
36
IO_1-
IO_2- (UART Rx B)
37
38
IO_3-
IO_4- (UART Rx C)
39
40
IO_5-
IO_6- (UART Rx D)
41
42
IO_7-
GND
43
44
IO_8- (UART Tx A)
IO_9- (UART Tx B)
45
46
IO_10- (UART Tx C)
IO_11- (UART Tx D)
47
48
IO_12-
IO_13- (SCC Rx B)
49
50
IO_14-
IO_15- (SCC Tx B)
51
52
GND
OUT_0 (UART Tx A)
53
54
OUT_1 (UART Tx B)
OUT_2 (UART Tx C)
55
56
OUT_3 (UART Tx D)
OUT_4 (SCC Tx A)
57
58
OUT_5
OUT_6
59
60
OUT_7
GND
61
62
AUX_OUT_0 (SCC RTS A) AUX_OUT_1
63
64
FIGURE 13
PMC-4U PN4 INTERFACE
