Avalon Stoves CHELAN B-VENT 700 B-VENT - Manual (Page 25)

L
ISTING
I
NFORMATION
P AGE 25
The safety label can be found on the rear panel. A copy is shown below.
Listed Gas-Fired Vented Room Heater
Tested to ANSI Z21.11.1-1991, ANSI Z21.11.1a-1993, CAN/CGA 2.1M88, CAN/CGA 2.17M91
By OMNI Environmental Services (Report #028-S-09-5, January 1996)
Must be installed in accordance with all local codes, if any; if not, follow ANSI Z223.1 in USA, CAN B149 in Canada, and the requirements listed
in the accompanying owner's manual.
Electrical connections and grounding must be installed in accordance with local codes, if any; if not, follow ANSI/NFPA 70 in USA or CSAC 2.21
in Canada.
Controls: Robertshaw Model 7000MVRB-5-LC
This room heater is equipped at the factory for use with natural gas, if conversion to propane (LP) fuel is desired, the optional
factory conversion kit #98900745 must be used.
Input and Orifice Specifications: L.P. N.G.
Maximum Input Rating (BTU/Hr) 38,000 40,000
Minimum Input Rating (BTU/Hr) 20,000 23,000
Front Burner Orifice (DMS) #49 #31
Pressure Specifications: L.P. N.G.
Manifold Pressure HI Setting (in W.C.) 10У 3.5У
Manifold Pressure LO Setting (in W.C.) 2.7У 1.0У
Minimum Inlet Pressure (in W.C.) 11У 5.5У
Minimum Clearance to Combustibles
Unit to Sidewall ....................................................10
Unit to Backwall .....................................................4
Unit to Cornerwall ..................................................4
Side Facing to Unit ................................................8
Top Facing to Unit .................................................8
Alcove Minimum Width .......................................44
Alcove Minimum Height ......................................58
Alcove Maximum Depth ......................................45
Front of Unit .........................................................36
Mantle Height Above Unit ................................17.5
Hearth Extension Front .........................................0
Hearth Extension Sides.........................................0
Use only with ÒBÓ vent listed chimney
"
"
"
"
"
"
"
"
"
"
"
"
Blower Electrical Rating: 115 Volts, 1.5 Amps, 60 Hz. FAN TYPE VENTED CIRCULATOR
WARNING:
Operation of this heater when not connected to a properly installed and maintained venting system of tampering with the vent safety shutoff
system can result in carbon monoxide (CO) poisoning and possible death.
Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to the information in the
owner's manual provided with this appliance. For assistance or additional information consult a qualified installer, service agency or the gas
supplier.
Risk of electrical shock. Disconnect power before servicing unit.
This room heater needs fresh air for safe operation and must be installed with provisions for adequate combustion and ventilation air. See
ownerÕs installation and operating instructions.
10850 117th Pl. N.E. Kirkland, WA 98033
1997
1998
1999
Jan.
Feb.
Mar.
Apr.
May
Jun.
Jul.
Aug.
Sep.
Oct.
Nov.
Dec.
Manufacture
Date:
DO NOT REMOVE THIS LABEL MADE IN U.S.A.
Beaverton,
OR. USA Tested &
Listed by TM
700
B-VENT
