E
INTERIOR
E - 3
Monitor Panel
The monitor panel allows you to check the amount of fluid in your fresh water tank, black
water tank, and the gray water tank. The LP gas and battery status are also shown.
Further instructions on its use are detailed in the electrical section of this manual.
The MicroPulse Monitor will display the condition of each system at all times. The
tri-color LED beside the system will indicate the condition of the system using the
following color code.
Fresh Water, LP Gas, Battery are as follows:
Green LED = 3/8 to Full
Yellow LED = 1/4
Red LED = 1/8 to Empty
Gray Water, Black Water are as follows:
Green LED = Empty to 5/8
Yellow LED = 3/4
Red LED = 7/8 to Full
Water Heater Switch
The water heater switch with a red indicator light is for lighting the water heater and
is located on the CS wall above the rear desk on the 22 Ft. model, on the galley wall
in the 16 ft, 25 ft. sleep six and 28 Ft. and on the lavatory wall in the 19 ft. and 23 ft.
models.
Water Pump Switch
The water pump switch is located on monitor panel. Once the switch is turned on, the
pump will run until the water pressure reaches about 65 psi. At this point, an internal
pressure switch will shut it off. When a faucet is open, the water pressure will drop and
the pump will start to run again. The water pump should be turned off when the trailer
is left unattended and when city water is being used as the fresh water supply.
Bathroom Exhaust Fan
The bathroom exhaust fan is in the bathroom ceiling and is opened by pushing up on
the handle running across the fan opening.
Shower Head
The lavatory sink spout pulls out for the shower head. It is designed to give maximum
flexibility in usage, and provides for water saving techniques when using your trailer on
self-containment. It can be held in the hand and moved about the body. Normally the
best water conservation procedure is to wet the entire body and then turn the water
off. Apply soap, lather thoroughly, and then rinse the soap off. The telephone shower
head is also used to fill the tub for taking a bath.
The 16 ft. Bambi has the added feature of using your shower head has an exterior
shower. An exterior door is provided to run the shower head and hose to the outside
of your trailer for clean up before entering.
