32
Mounting more than one
hob
Cutting out
The measurement of the selected combination is calculated in the following way:
Depth: 490 mm
Width:
1. Calculate the sum of all units’ width.
2. Subtract 20 mm from the total width.
Example:
A hob of 720 mm + a downdraft of 180 mm + a gas hob of 360 mm.
1. 720+180+360= 1260 mm
2. Width of the hole: 1260-20=1240 mm
Distance to Wall:
Min. 150 mm to flammable material.
Min. 50 mm to non-flammable material
49
0 m
m
Reinforcement beam
Distance to wall:
Min. 50 mm
(
non-flammable material)
Distance to wall:
Min. 150 mm
(flammable material)
13
Turn off a single zone by pressing
the
m
or
l
buttons until the dis-
play shows “0”. You can turn off a
zone quickly by pressing the
l
and
m
buttons simultaneously.
Turn off all zones by pressing the
k
button.
Residual Heat Indicator
Each cooking zone has a residual
heat indicator. When the cooking
zone is turned off the “H” is lit up in
the display until the cooking zone
has cooled. “H” is a warning that the
cooking zone is still hot.
