Albatron Technology DM-5952KF - Manual (Page 11)

18
10. ACCESSING THE MAIN MENU
Access the OSD Menu by control panel on the monitor or the remote control
to make the operation.
Screen-1 Screen-2 Screen-3
Screen-4 Screen-5 Screen-6
Screen-7 Screen-8 Screen-9
OSD FUNCTION CHART
19
Following lists the function keys on the OSD:
Note:
Press the Menu button on the control panel or the remote
control to display the main menu.
Press the SEL +/- buttons on the control panel or remote control
to scroll through the menu.
Press the VOL +/-buttons on the control panel or the remote
control to adjust the setting values.
Press Sub-menu to return to upper level while in any sub-menu.
To exit the menu mode, press the menu button while in the top-
level menu.
MAIN MENU
Picture Menu Fine tunes the Picture image quality manually:
CONTRAST 、 BRIGHTNESS 、 H ∕ V SIZE 、 H ∕ V
POSITION、PINCUSHION、TRAPEZOID、TOP-CORNER、
BOTTOM-CORNER、 PIN-BALANCE 、 PARALLELORGAM 、
ROTATION and RECALL.
Note：
a. Recall will replace current settings by the factory-preset values. You can
only recall factory settings when the PC mode is in one of the 14 predefined
modes. See Table 3 appendix B for preset modes. Color recall is used to
call back the factory setting of R.G.B.
b. Above parameters is for PC mode only, and can’t be reached in TV ∕AV
mode. In TV∕AV mode, you can adjust the TV parameters by remote
control.
Color Menu Select the color temperature to make colors more pure
and vivid. Select user item to adjust the color intensity
by VOL＋∕－key.
Audio Menu Fine tune the audio functions manually:
Bass、Treble、Balance、Volume.
