GA-M61P-S3 Motherboard - 32 -
English
2-1 Standard CMOS Features
Date
The date format is , , , .
Week The week, from Sun to Sat, determined by the BIOS and is display-only
Month The month, Jan. Through Dec.
Day The day, from 1 to 31 (or the maximum allowed in the month)
Year The year, from 1999 through 2098
Time
The times format in . The time is calculated based on the 24-hour
military-time clock. For example, 1 p.m. is 13:00:00.
IDE Channel 0 Master/Slave
IDE HDD Auto-Detection
Press "Enter" to select this option for automatic device detection.
IDE Channel 0, Master/Slave IDE/SATA Device Setup. You can use one of three methods:
• Auto Allows BIOS to automatically detect IDE/SATA devices during POST(default)
• None Select this if no IDE/SATA devices are used and the system will skip the
automatic detection step and allow for faster system start up.
• Manual User can manually input the correct settings
Access Mode Use this to set the access mode for the hard drive. The four options are:
CHS/LBA/Large/Auto(default:Auto)
IDE Channel 2, 3, 4, 5 Master
IDE Auto-Detection
Press "Enter" to select this option for automatic device detection.
Extended IDE Drive. IDE/SATA Device Setup. You can use one of the two methods:
• Auto Allows BIOS to automatically detect IDE/SATA devices during POST. (default)
CMOS Setup Utility-Copyright (C) 1984-2006 Award Software
Standard CMOS Features
Date (mm:dd:yy) Mon , Oct 2 2006
Time (hh:mm:ss) 22:31:24
` IDE Channel 0 Master [None]
` IDE Channel 0 Slave [None]
` IDE Channel 2 Master [None]
` IDE Channel 3 Master [None]
` IDE Channel 4 Master [None]
` IDE Channel 5 Master [None]
Drive A [1.44M, 3.5"]
Floppy 3 Mode Support [Disabled]
Halt On [All, But Keyboard]
Base Memory 640K
Extended Memory 447M
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level`
