Thermo Scientific Agilent 1100 Series LC Devices Connecting the Hardware and Triggering Data Acquisition 17
A
Upgrading an HP 1100 Series LC
The Xcalibur 2.0 and higher data system supports control of the Hewlett-Packard (HP)
1100 Series LC only if you upgrade the HP 1100 communication interface to an Ethernet
interface.
Y To upgrade your HP 1100 Series LC
1. Order the appropriate upgrade parts from your local office for Thermo Electron San Jose
products:
• If the HP 1100 is not interfaced to an MS detector as an Xcalibur-controlled GPIB
inlet device, order the JetDirect Ethernet Control kit, which contains the parts listed
in
Table 4 .
• If the HP 1100 is interfaced to an MS detector as an Xcalibur-controlled GPIB inlet
device, order the parts listed in Table 5 .
Note An HP 1100 LC system that is currently interfaced to a MS detector as an
Xcalibur-controlled GPIB inlet device should have already installed the contact
closure PCB and the external contact closure cable. Therefore, you need to order
only the parts specified in
Table 5 .
Table 4. JetDirect Ethernet Control Kit (P/N OPTON 30018)
Part Number Description of Kit
00012-27714 Contact closure PCB
00012-27716 External contact closure cable
00012-70008 Ethernet 10 Base-T cable (2)
00825-01-00024 10/100 Autosensing 8-port Ethernet switch
00825-01140 HP JetDirect 400N PCB
