- 16 -
VII .SPECIFICATIONS
Wood Saw (EY3551)
Motor voltage 18 V DC
Blade Speed 2900 /min (rpm)
Blade Size
Outside diameter 165 mm (6-1/2")
Arbor size 20 mm (25/32")
Maximum cutting depth
3-56 mm (1/8"-2-7/32") ( φ 165mm blade)
50° angle cutting .... 32 mm (1-9/32")
Dimensions (L × W × H)
375 Ч 200 Ч 264 mm
(14-3/4" Ч 7-7/8" Ч 10-13/32")
Cutting angle adjustment 0 - 50°
Weight (with battery pack) 4 k g (8.82 lbs)
Battery Pack (EY9251)
Storage Battery Ni-MH Battery
Voltage 18 V DC (1.2 V × 15 cells)
Battery Charger (EY0110)
Model EY0110
Electrical rating See the rating plate on the bottom of the charger.
Weight 0.78 k g (1.72 lbs)
Charging time 65 minutes (EY9251)
NOTE:
• Do not charge “Y” type Ni-Cd battery packs.
• For applicable battery packs to this charger, see the label on the charger or the latest general
catalog.
