Panasonic DMWMCTZ3E - Manual (Page 11)

11
VQT1F26
2
Check the O-ring.
≥
Check that there is no dirt, sand, hair, dust, salt crystals, lint or old grease on
the O-ring. If you find any of these, remove them with a soft, dry cloth.
≥
There may be dirt on the O-ring that you cannot see. Check if there is any dirt by
rubbing your finger over the O-ring.
≥
Be careful not to leave any fibers from the dry cloth on the O-ring when wiping it.
≥
Check that the O-ring is not ripped, twisted, squashed, frayed or scratched and
that there is no sand sticking to it. Replace the O-ring in these cases.
3
Inspect the O-ring groove.
≥
Grains of sand or hardened salt crystals may get into the O-ring groove.
Remove them carefully with an air spray or a cotton swab. If you use a cotton
swab, be careful not to leave any fibers from it in the O-ring groove.
3 Dirt
3 Sand 3 Hair
3
Dust
3 Salt crystals 3 Lint
3 Ripped 3 Twisted 3 Squashed 3 Frayed
3 Scratched 3 Sand sticking
