- 42 -
About the Control Buttons
After enabling RS-485 function, the control panel will appear on the Live View window.
Control Buttons of RS-485
- Left/Right/Up/Down/Home buttons allow you to move the camera lens position. Clicking the
Home (center) button will move the camera lens to the assigned home position.
- Click the Number button (1~8) to move the camera lens to the preset position immediately.
To set up the preset positions, move the camera lens by clicking the Left/Right/Up/Down buttons
to the desired position first, and then select the number (1~8) from the pull-down list and click the
Apply button. You can enter a descriptive name for the assigned position in the text box to
identify it easily.
- Pan Speed: Adjust the moving speed (1 ~ 10) while panning the lens.
- Tilt Speed: Adjust the moving speed (1 ~ 10) while tilting the lens.
Right
Down
Home
Up
Left
