Control reference guide
5
4
1
2
3
6 7 8 9 10
11
13
14
12
1 Terminal cover
2 Strap hole
3 AUX IN jack (> 10)
• Recommended plug type: Straight Plug
4 DC IN terminal
5 RESET
• Use a paper clip, etc., to press the
switch if this unit does not operate
correctly, like when you cannot turn
off/on the power.
6 Battery indicator (red) (> 6)
• Indicates the battery status.
7 Bluetooth ® indicator (blue)
8 Boost Mode indicator (orange)
9 Boost button (> 10)
10 Microphone (> 11)
11 Standby/on switch [Í/I]
• Press to switch the unit from on to
standby mode or vice versa. In
standby mode, the unit is still
consuming a small amount of
power.
12 Bluetooth ® pairing button
(> 7)/Play button (below)/
Pause button
(below)/Receiver
button (> 11)
• Play / Pause: Press this button to
switch between play and pause
while playing music with the paired
device.
13 NFC touch area (> 8)
14 Volume buttons
4
