Notes on Speakers
• Decrease the volume when the audio is distorted.
Specifications
Amplifier section
Output power
RMS Output Power
10 % total harmonic distortion
Front ch (both ch driven):
2 W per channel (1 kHz, 6 ≠, Boost Mode)
Total RMS power:
4 W
Speaker section
Front Speaker (L/R)
Type:
1 way 1 speaker system
(Passive Radiator)
Unit(s):
φ 34 mm
Impedance:
6 ≠
Passive Radiator:
φ 50 mm
Bluetooth ® section
Bluetooth ® system specification:
Bluetooth ® Ver. 3.0
Wireless equipment classification:
Class 2 (2.5 mW)
Supported profiles:
A2DP/AVRCP/HFP
Supported codec:
SBC
Frequency band:
2.4 GHz band FH-SS
Operating distance:
Approx. 10 m Line of Sight
Prospective communication distance.
Measurement environment:
Hight 1.0 m
Microphone section
Type:
Mono
Terminals section
DC IN:
USB Micro Type B
AUX input:
Stereo 3.5 mm jack
General
Power supply:
DC IN 5 V 0.5 A
Internal Battery 3.6 V (NiMH 1500 mAh)
Battery Life in Use:
Approx. 8 h (Normal Mode, Bluetooth ® )
Approx. 1.5 h (Boost Mode, Bluetooth ® )
Battery Charge Time:
Approx. 5 h
Dimensions (W k H k D):
120 mm k 53.8 mm k 120 mm
Mass:
Approx. 330 g
Operating temperature range:
-10 oC to i50 oC
Operating humidity range:
35% to 80% RH (no condensation)
Splash Proof:
IPX4 equivalent
Shock Proof:
76 cm Drop
Note
• Specifications are subject to change without notice. Mass and dimensions are approximate.
• Total harmonic distortion is measured by a digital spectrum analyzer.
