4. Remove the handle:
Unscrew the handle from the top (A1)
and the bottom (A2) of the door.
Unscrew both of the handle brackets
from the handle rod and re-screw the
handle brackets provided in the handle
kit.
5. Unscrew the hinge (B1) and remove the
cover plate (B2) and the support (B3).
Remove the cover (B4) on the opposite
side and install the support (B3) the
cover plate (B2) and the hinge (B1). In-
stall the cover (B4) on the opposite side.
6. Unscrew the lower hinge (C1). Move the
pin to the opposite side (C2). Unscrew
and move the pedal to the opposite side
(C3).
Screw on the lower hinge on the oppo-
site side.
7. Tighten the pin with the adjustment
spanner supplied.
8. Install the handle on the opposite side.
9. Raise the appliance and install the ven-
tilation grille.
10. Put the cabinet in position.
WARNING!
Reposition, level the appliance, wait for at least four hours and then connect it to the pow-
er socket.
Do a final check to make sure that:
• All screws are tightened.
a1 a2
B1
B3 B4
B2
C2
C3
C1
Installation 19
