Part names
Control panel
(1) STANDBY/ON button (13)
(2) INPUT/ENTER button (14, 20)
(3) MENU button (20)
It consists of four cursor buttons.
(4) POWER indicator (13, 57)
(5) TEMP indicator (57)
(6) LAMP indicator (57)
Remote control
(1) VIDEO button (15)
(2) COMPUTER button (14)
(3) MY SOURCE/DOC.CAMERA button (15)
(4) STANDBY/ON button (13)
(5) ASPECT button (15)
(6) AUTO button (17)
(7) SEARCH button (15)
(8) BLANK button (19)
(9) MAGNUFY - ON button (12, 18)
(10) MAGNIFY - OFF button (12)
(11) FREEZE button (19)
(12) PAGE UP button (12)
(13) PAGE DOWN button (12)
(14) VOLUME + button (14)
(15) VOLUME - button (12, 14)
(16) KEYSTONE button (18)
(17) MY BUTTON - 1 button (40)
(18) MY BUTTON - 2 button (40)
(19) MUTE button (14)
(20) POSITION button (17)
(21) MENU button (20)
(22) ▲/▼/◄/► cursor buttons (12, 20)
(23) ENTER button (12, 20)
(24) ESC button (12, 20)
(25) RESET button (12, 20)
(26) Battery cover (11)
