Specifications
SDM-S53
LCD panel
Panel type: a-Si TFT Active Matrix
Picture size: 15.0 inch
Input signal format
RGB operating frequency*
Horizontal: 28 – 61 kHz
Vertical: 48 – 75 Hz
Resolution
Horizontal: Max.1024 dots
Vertical: Max.768 lines
Input signal levels
RGB video signal
0.7 Vp-p, 75
Ω, positive
SYNC signal
TTL level, 2.2 k
Ω,
positive or negative
(Separate horizontal and vertical,
or composite sync)
0.3 Vp-p, 75
Ω, negative
(Sync on green)
Power requirements
100 – 240 V, 50 – 60 Hz,
Max. 0.6 A
Power consumption
Max. 25 W
Operating temperature
5 – 35
°
C
Dimensions (width/height/depth)
Display (upright):
Approx. 339
Ч 370
Ч 186 mm
(13
3
/
8
Ч 14
5
/
8
Ч 7
3
/
8
inches)
(with stand)
Approx. 339
Ч 275
Ч 53 mm
(13
3
/
8
Ч 10
7
/
8
Ч 2
1
/
8
inches)
(without stand)
Mass
Approx. 3.7 kg (
8 lb 2 oz)
(with stand)
Approx. 2.7 kg (
5 lb 15 oz)
(without stand)
Plug & Play
DDC2B
Accessories
SDM-S73/S93
LCD panel
Panel type: a-Si TFT Active Matrix
Picture size: 17.0 inch (SDM-S73)
Picture size: 19.0 inch (SDM-S93)
Input signal format
RGB operating frequency*
Horizontal: 28 – 80 kHz
Vertical: 48 – 75 Hz
Resolution
Horizontal: Max.1280 dots
Vertical: Max.1024 lines
Input signal levels
RGB video signal
0.7 Vp-p, 75
Ω, positive
SYNC signal
TTL level, 2.2 k
Ω,
positive or negative
(Separate horizontal and vertical,
or composite sync)
0.3 Vp-p, 75
Ω, negative
(Sync on green)
Power requirements
100 – 240 V, 50 – 60 Hz,
Max. 1.0 A
Power consumption
Max. 45 W (SDM-S73)
Max. 50 W (SDM-S93)
Operating temperature
5 – 35
°
C
Dimensions (width/height/depth)
Display (upright):
Approx. 367
Ч 411
Ч 215 mm
(14
1
/
2
Ч 16
1
/
4
Ч 8
1
/
2
inches)
(with stand) (SDM-S73)
Approx. 412
Ч 445
Ч 234 mm
(16
1
/
4
Ч 17
5
/
8
Ч 9
1
/
4
inches)
(with stand) (SDM-S93)
Approx. 367
Ч 315
Ч 60 mm
(14
1
/
2
Ч 12
1
/
2
Ч 2
3
/
8
inches)
(without stand) (SDM-S73)
Approx. 412
Ч 350
Ч 64 mm
(16
1
/
4
Ч 13
7
/
8
Ч 2
5
/
8
inches)
(without stand) (SDM-S93)
Mass
Approx. 5.4 kg (
11 lb 14 oz)
(with stand) (SDM-S73)
Approx. 6.6 kg (
14 lb 8 oz)
(with stand) (SDM-S93)
Approx. 4.1 kg (
9 lb)
(without stand) (SDM-S73)
Approx. 5.2 kg (
11 lb 7 oz)
(without stand) (SDM-S93)
Plug & Play
DDC2B
Accessories
* Recommended horizontal and vertical timing condition
• Horizontal sync width duty should be more than 4.8% of total
horizontal time or 0.8 µs, whichever is larger.
• Horizontal blanking width should be more than 2.5 µsec.
• Vertical blanking width should be more than 450 µsec.
Design and specifications are subject to change without notice.
