15
GB
Technical Features
Power saving function
This monitor meets the power-saving guidelines set by VESA,
E NERGY S TAR, and NUTEK. If the monitor is connected to a
computer or video graphics board that is DPMS (Display Power
Management Signaling) compliant, the monitor will automatically
reduce power consumption as shown below.
SDM-S53
SDM-S73
SDM-S93
* When your computer enters the “active off” mode, the input signal is
cut and NO INPUT SIGNAL appears on the screen. After 5 seconds,
the monitor enters the power saving mode.
** “deep sleep” is the power saving mode defined by the Environmental
Protection Agency.
Reducing the power consumption
(ECO mode)
If you press the ECO button on the front of the monitor, the
backlight level and the power consumption are reduced.
The “ ECO: ON” menu appears on the screen and the backlight
level is reduced. The menu automatically disappears after about 5
seconds.
To cancel the ECO mode
The “ECO: OFF” menu appears on the screen and normal
backlight level is set. The menu automatically disappears after
about 5 seconds.
Automatic picture quality
adjustment function
When the monitor receives an input signal, it
automatically adjusts the picture’s position and
sharpness (phase/pitch), and ensures that a clear
picture appears on the screen.
The factory preset mode
When the monitor receives an input signal, it automatically
matches the signal to one of the factory preset modes stored in the
monitor’s memory to provide a high quality picture at the center
of the screen. If the input signal matches the factory preset mode,
the picture appears on the screen automatically with the
appropriate default adjustments.
If input signals do not match one of the factory
preset modes
When the monitor receives an input signal that does not match one
of the factory preset modes, the automatic picture quality
adjustment function of this monitor is activated to ensure that a
clear picture always appears on the screen (within the following
monitor frequency ranges):
Horizontal frequency: 28–61 kHz (SDM-S53)
28–80 kHz (SDM-S73/S93)
Vertical frequency: 48–75 Hz
Consequently, the first time the monitor receives input signals
that do not match one of the factory preset modes, the monitor
Power mode Power consumption 1 (power)
indicator
normal
operation 25 W (max.) green
active off*
(deep sleep)** 1 W (max.) orange
power off 1 W (max.) red
main power off 0 W off
Power mode Power consumption 1 (power)
indicator
normal
operation 45 W (max.) green
active off*
(deep sleep)** 1 W (max.) orange
power off 1 W (max.) red
main power off 0 W off
Power mode Power consumption 1 (power)
indicator
normal
operation 50 W (max.) green
active off*
(deep sleep)** 1 W (max.) orange
power off 1 W (max.) red
main power off 0 W off
ECO
E C O : O N
,
Press the ECO button.
ECO
E C O : O F F
,
Press the ECO button again.
(continued)
