Cyclades-PR4000
Chapter 15 - IPX 140
The parameter Send SAP Update can be set to Demand, Periodic, or None. This parameter affects both SAP and
RIP. Periodic causes the router to send these messages every minute, while choosing Demand will cause the
router to send messages only when a message request is received.
Frame Relay
Frame Relay parameters are explained in chapter 10. The IPX-protocol-specific parameters are the same as
those described in the preceding section, but are located in the menu CONFIG =>INTERFACE =>
=>ENCAPSULATION =>FRAME RELAY => => ADD DLCI.
X.25
X.25 is explained in chapter 10. The IPX-protocol-specific parameters are the same as those described in the
PPP section, but are located in the menu CONFIG =>INTERFACE => =>ENCAPSULATION =>X25
=> => ADD DTE.
Routing
Routing can be done statically, by configuring static routes, or dynamically using RIP. RIP is described in chapter
11. To create a static route, as shown in Figure 13.1, navigate to the menu CONFIG => STATIC ROUTES => IPX
=>ADD ROUTE. The parameters for the system shown in the example are the following:
Add IPX Static Route Menu CONFIG => STATIC ROUTES => IPX =>ADD ROUTE
Parameter Value for the Example
Destination Network
Number 00010001
Interface Slot 1
Next Hop Node 00602e001100
Number of Hops 1 (one router is between the router being configured and the network to be reached)
Number of Ticks 1 (related to the time necessary to reach the network)
