6
Operating Instructions
Connecting Additional Equipment
TV and VCR
1
Connect the coaxial cable from your TV antenna or cable service to
the IN jack on your VCR.
2
Using a coaxial cable (not supplied), connect the OUT jack on your
VCR to the VHF/UHF jack on the TV.
Optional connection
If your VCR is equipped with video outputs, you can get better picture
quality by connecting Audio/Video cables (not supplied) from AUDIO
and VIDEO OUT on your VCR to AUDIO/VIDEO IN on your TV.
To watch video programs from your VCR, tune your TV to channel 3 or 4 (as
set on the rear of your VCR).
For optimum picture quality, use S VIDEO instead of the yellow Audio/ Video
cable. S VIDEO does not provide sound; the audio cables must still be
connected.
You can use the button to switch between the VHF/UHF and VIDEO
inputs.
2
1
From cable/
antenna
VCR
Optional connection
Rear of TV
Video (yellow)
Audio L (white)
Audio R (red)
