the compressed air cylinder when you do not
use your compressed air rifle.

• Screw the compressed air cylinder 2 turns

out.

• Cock the rifle and release the trigger so

that the remaining air can escape.

• Repeat this process once or twice.
• Screw out the compressed air cylinder

completely by 3-4 further turns.

• Thus the compressed air cylinder can be

screwed out without any pressure on the
o-ring.

To change the compressed air cylinder

• Screw out the compressed air cylinder by

turning it counter-clockwise either
manually or with a key. Attention: Screw
out the compressed air cylinder until you
hear the air escape (at least four turns).
Then screw in the compressed air cylinder
again. Thus a damage to the seals will
be avoided.

To fill the compressed air cylinder

Before you fill the compressed air cylinder,
please check all components which are used
in this process such as refill bottle, refill adapter

and compressed air cylinder for defects (e.g.
at the threads).

Warning

• Only use refill bottles with a maximum

pressure of 200 bar (2,790 psi)

• Only use compressed air free of oil and

water (DIN EN 12021).

• Make sure that there is no oil or grease

on the connecting threads.

• Only use the original ANSCHÜTZ refill

adapter(Order No. 711.3409), which is
delivered with your rifle.

• To refill the compressed air cylinder we

recommend the use of diving bottles.

Filling process

• Screw the adapter on the refill bottle.
• Screw the compressed air cylinder onto

the adapter.

• Tighten the hexagon screw of the adapter

by hand to prevent air escape.

• Open the valve of the bottle very slowly

until no more flow noise is audible.

• Close the valve of the compressed air

bottle after approx. 5 seconds (The com-
pressed air cylinder will heat up slightly).

• Empty the adapter by releasing the hex

screw.

• Screw the hex screw into the adapter

again.

• Remove the compressed air cylinder and

screw it on the rifle by hand.

With a full cylinder (max. 200 bar/2790 psi)
approx. 300 shots (remaining pressure 65 bar
/ 943 psi) can be fired. With a Junior
compressed air cylinder 175 shots can be
fired. We recommend to never empty the
compressed air cylinder completely.
Compressed air bottles (Order No.
711.3510) are available in specialized gun
shops. The refilling of compressed air cylinders
is also possible in specialized gun shops or
in shops for diving equipment.

Warning

Compressed air refill bottles with an allowed
filling pressure of 300 bar (4,185 psi) are
offered as well. These bottles have the same
thread as the bottles with a filling pressure of
200 bar (2,790 psi). In case you use a bottle
with a filling pressure of 300 bar (4,185 psi)
it is absolutely necessary to use a pressure
reducer which is adapted to 200 bar /2,790
psi). For reasons of safety it is not allowed to
fill the compressed air cylinder with more than
the maximum pressure of 200 bar (2,790 psi).

Warning

Only original ANSCHÜTZ compressed air
cylinders (max. 200 bar) must be used!
Repair of compressed air cylinders must only
be carried out by the manufacturer. Original
spare parts must be used. If this is not
observed we will not assume any liability or
warranty.

To attach the compressed air cylinder

The compressed air cylinder must be screwed
in horizontally, slowly an carefully to avoid
any damage.

Attention

• Fill the compressed air cylinder before use

and screw it in manually.

• You feel a resistance before you reach

the stop, the valve thus opens auto-
matically.

• Screw the compressed air cylinder in for

approx. one more turn until there is an
airtight connection at the stop.

To remove the compressed air cylinder

To protect the housing, valves, seals and
springs we recommend you always remove
