CONTROLS AND FUNCTIONS

1. Platter -

This platter connects directly to the center spindle

(8). The platter and center spindle (8) holds a vinyl

record perfectly center. The platter also spins the

record at a consistent speed.

2. Tone Arm Assembly -

This assembly will be explained in tonearm section

on the page 14.

3. Pitch Adjust Slider -

This slider is used to adjust the playback pitch

percentage (platter speed). Use this slider to match

the BPM’s of this unit to that of another music

source.

4. Record/Stop Button -

This button is used to start and stop recording to

your USB stick.

5. 45-rpm Speed Selector Buttons -

Engaging this button will rotate the platter at 45

RPMs. A function LED will glow when this function

is activated.
