STR-DA3500ES
4-144-907-11(1)
Other Oper
ations
J D.RANGE Lights up when dynamic range
compression is activated.
K CAT Lights up when category mode
is selected during the satellite
radio operation.
L Tuner
indicators
Lights up when using the
receiver to tune in radio
stations, etc.
M SP A/SP B/
SP A+B
Lights up according to the
speaker system used (page 44).
However, these indicators do
not light up if the speaker
output is turned off or if
headphones are connected.
N SLEEP Lights up when the sleep timer
is activated.
O ZONE 2/
ZONE 3
Lights up while operation in
zone 2/zone 3 is being enabled.
P A.DIRECT Lights up when the receiver is
processing Analog Direct
signals.
Q SIRIUS Lights up when the
SiriusConnect Home tuner is
connected and “SIRIUS” is
selected.
R MEM Lights up when a memory
function, such as Preset
Memory, etc., is activated.
S XM Lights up when XM Mini
Tuner and Home Dock are
connected and “XM RADIO”
is selected.
T ; PL/
; PL II/
; PL IIx
“; PL” lights up when the
receiver applies Dolby Pro
Logic processing to 2 channel
signals in order to output the
center and surround channel
signals.
“; PL II” lights up when the
Dolby Pro Logic II decoder is
activated.
“; PL IIx” lights up when the
Dolby Pro Logic IIx decoder is
activated.
However, these indicators do
not light up if there are no
center and surround speakers
and you select a sound field
using the A.F.D. button.
Name Function
U BI-AMP Lights up when “Sur Back
Assign” is set to “BI-AMP”.
V EQ Lights up when the equalizer is
activated.
W LPCM Lights up when Linear PCM
signals are detected.
X ANALOG Lights up when
– INPUT MODE is set to
“AUTO” and no digital signal
is being input through the
COAXIAL, OPTICAL or
HDMI jacks.
– INPUT MODE is set to
“ANALOG”.
– the “2ch Analog Direct” is
being used.
Y DMPORT Lights up when DIGITAL
MEDIA PORT adapter is
connected and “DMPORT” is
selected.
Z MULTI IN Lights up when multi channel
input is selected.
wj HDMI Lights up when the receiver
recognizes a component
connected via an HDMI IN
jack.
Name Function
continued
