Operating Instructions
10
Connecting Additional Equipment
Connecting a TV and VCR
1 Connect the coaxial cable from your TV antenna or cable service to the IN jack on your VCR.
2 Connect a coaxial cable (not supplied) from the OUT jack on your VCR to the VHF/UHF jack on
the TV.
Optional connection
If your VCR is equipped with video outputs, you can get better picture quality by connecting audio/video
cables (not supplied) from AUDIO/VIDEO OUT on your VCR to AUDIO/VIDEO IN on your TV.
✍
To watch video programs from your VCR, tune your TV to channel 3 or 4 (as set on the rear of your
VCR).
✍
You can use the button to switch between the VHF/UHF and VIDEO inputs.
✍
For better picture quality, use S VIDEO instead of the yellow video cable. S VIDEO does not provide
sound; you still must connect the audio cables.
1 3 4
Optional connection
VCR
2
Rear of TV
1
From
cable/antenna
Video (yellow)
Audio R (red)
Audio L (white)
