Sony FWD-40LX1 - Manual (Page 22)

FWD-40LX1
FWD-32LX1R
18
Code Table(4-d)
[a]Function [b]Range/Switch code Command
Control
Enquiry Standby Power On
0x11 Shutdown Log 0x00 - 0xFF No Yes Enable Enable
0x12 Digital 3.3 V(Failure) 0x00 - 0xFF
0x13 Digital 5 V(Failure) 0x00 - 0xFF
0x14 Analog5 V/9 V(Failure) 0x00 - 0xFF
0x20 Busy to INPUT * 0x00 Non Busy
0x01 Busy
* Busy to INPUT should be judged by Busy → Non Busy. Busy to INPUT may be incorrectly judged during start when it is judged by only Non Busy.
8. User Reset
Syntax Header Category Function Data1 Data2 Check Sum
Control 0x8C 0x50 Code Table(5) 0x02 0xFF 0xXX
Answer Header Answer Check Sum
Control 0x70 0x00 0x70 Completed
0x70 0x03 0x73 Command Canceled
Code Table(5)
Function Range/Switch code Command
Control
Enquiry Standby Power On
0x00 Picture Reset Yes No Disable Enable
0x01 Audio Reset
0x03 Picture Reset2 Contrast, Brightness, Chroma, Phase
0x04 All Reset
