About This Manual
• The instructions in this manual are for model
HT-DDW870. Check your receiver’s model number
by looking at the lower right corner of the front
panel. In this manual, the model of area code U is
used for illustration purposes unless stated otherwise.
• The instructions in this manual describe the controls
on the receiver. You can also use the controls on the
supplied remote if they have the same or similar
names as those on the receiver. For details on the use
of your remote, see pages 42–50.
The HT-DDW870 consists of:
Models of area code U, CA
• Receiver STR-K870P
• Speaker system
– Front speaker (left) SS-MSP67L
– Front speaker (right) SS-MSP67R
– Center speaker SS-CNP67
– Surround speaker (left) SS-MSP67SL
– Surround speaker (right) SS-MSP67SR
– Surround back speaker SS-MSP67SB
– Sub woofer SA-WMSP87
Models of area code CEL, CEK
• Receiver STR-K870P
• Speaker system
– Front speaker (left) SS-MSP87L
– Front speaker (right) SS-MSP87R
– Center speaker SS-CNP87
– Surround speaker (left) SS-MSP87SL
– Surround speaker (right) SS-MSP87SR
– Surround back speaker SS-MSP87SB
– Sub woofer SA-WMSP87E
Models of other area code
• Receiver STR-K870P
• Speaker system
– Front speaker (left) SS-MSP87L
– Front speaker (right) SS-MSP87R
– Center speaker SS-CNP87
– Surround speaker (left) SS-MSP87SL
– Surround speaker (right) SS-MSP87SR
– Surround back speaker SS-MSP87SB
– Sub woofer SA-WMSP87
This receiver incorporates Dolby* Digital and Pro
Logic Surround and the DTS** Digital Surround
System.
* Manufactured under license from Dolby
Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are
trademarks of Dolby Laboratories.
** “DTS”, “DTS-ES”, “Neo:6” and “DTS 96/24” are
trademarks of Digital Theater Systems, Inc.
Note for the supplied remote
For RM-AAP001
The AUX, MULTI CH and 12 buttons on the
remote are not available for receiver operation.
About area codes
The area code of the receiver you purchased is
shown on the lower portion of the rear panel (see
the illustration below).
Any differences in operation, according to the area
code, are clearly indicated in the text, for example,
“Models of area code AA only”.
SURROUND
FRONT A
SURROUND BACK
CENTER FRONT B
L R
L R
L R
L R
+ – –
EAKERS
+ –
SPEAKERS
2-XXX-XXX-XX AA
Area code
